| TYPE | Io(A) | VR(V) | VF(V) | IR(A) | Trr | Package | POLARITY | Pcm(mw) | Ic | Bvcbo(V) | Bvceo(V) | Bvebo(V) | Hfe Min | Hfe Max | VCC | Gi | VO(ON) | R1 | R2 |
| SB1035.pdf | 10 | 35 | 0.55 | 0.3mA | TO-277 |
| SB1045.pdf | 10 | 45 | 0.55 | 0.3mA | TO277 |
| SB1050.pdf | 10 | 50 | 0.55 | 0.3mA | TO-277 |
| SB1060.pdf | 10 | 60 | 0.70 | 0.3mA | TO-277 |
| SB10100.pdf | 10 | 100 | 0.70 | 0.3mA | TO-277 |
| SB10150.pdf | 10 | 150 | 0.80 | 0.3mA | TO-277 |
| SB10200.pdf | 10 | 200 | 0.85 | 0.3mA | TO-277 |
| ES1A.pdf | 1.0 | 50 | 0.95 | 5.0μA | SMAF |
| ES1B.pdf | 1.0 | 100 | 0.95 | 5.0μA | SMAF |
| ES1D.pdf | 1.0 | 200 | 0.95 | 5.0μA | SMAF |
| ES1G.pdf | 1.0 | 400 | 1.3 | 5.0μA | SMAF |
| ES1J.pdf | 1.0 | 600 | 1.3 | 5.0μA | SMAF |
| ES1K.pdf | 1.0 | 800 | 1.7 | 5.0μA | SMAF |
| ES1M.pdf | 1.0 | 1000 | 1.7 | 5.0μA | SMAF |
| ES5A.pdf | 5.0 | 50 | 0.95 | 5.0μA | SMC |
| ES5B.pdf | 5.0 | 100 | 0.95 | 5.0μA | SMC |
| ES5C.pdf | 5.0 | 150 | 0.95 | 5.0μA | SMC |
| ES5D.pdf | 5.0 | 200 | 0.95 | 5.0μA | SMC |
| ES5E.pdf | 5.0 | 300 | 1.25 | 5.0μA | SMC |
| ES5G.pdf | 5.0 | 400 | 1.25 | 5.0μA | SMC |
| ES5J.pdf | 5.0 | 600 | 1.7 | 5.0μA | SMC |
| SP1535L.pdf | 15.0 | 35 | 0.50 | 0.3mA | - | TO-277 |
| SP1545L.pdf | 15.0 | 45 | 0.50 | 0.3mA | - | TO-277 |
| SP1550L.pdf | 15.0 | 50 | 0.55 | 0.3mA | - | TO-277 |
| SP1560L.pdf | 15.0 | 60 | 0.55 | 0.3mA | - | TO-277 |
| SP15100L.pdf | 15.0 | 100 | 0.70 | 0.3mA | - | TO-277 |
| SP15150.pdf | 15.0 | 150 | 1.80 | 0.3mA | - | TO-277 |
| SP15200L.pdf | 15.0 | 200 | 0.85 | 0.3mA | - | TO-277 |
| SS22F.pdf | 2.0 | 20 | 0.55 | 0.5mA | - | SMAF |
| SS24F.pdf | 2.0 | 40 | 0.55 | 0.5mA | - | SMAF |
| SS26F.pdf | 2.0 | 80 | 0.70 | 0.3mA | - | SMAF |
| SS210Fpdf.pdf | 2.0 | 100 | 0.85 | 0.3mA | - | SMAF |
| SS212F.pdf | 2.0 | 120 | 0.85 | 0.3mA | - | SMAF |
| SS215F.pdf | 2.0 | 150 | 0.95 | 0.3mA | - | SMAF |
| SS220F.pdf | 2.0 | 200 | 0.95 | 0.3mA | - | SMAF |
| SS24.pdf | 2 | 40 | 0.55 | 500 | - | SMB |
| SS25.pdf | 2 | 50 | 0.75 | 500 | - | SMB |
| SS26.pdf | 2 | 60 | 0.75 | 500 | - | SMB |
| SS210.pdf | 2 | 100 | 0.85 | 500 | - | SMB |
| SS32.pdf | 3 | 20 | 0.55 | 500 | - | SMC |
| SS33.pdf | 3 | 30 | 0.55 | 500 | - | SMC |
| SS34.pdf | 3 | 40 | 0.55 | 500 | - | SMC |
| SS35.pdf | 3 | 50 | 0.75 | 500 | - | SMC |
| SS36.pdf | 3 | 60 | 0.75 | 500 | - | SMC |
| SS310.pdf | 3 | 100 | 0.85 | 500 | - | SMC |
| SK12.pdf | 1 | 20 | 0.45 | 500 | - | SMA-L |
| SK13.pdf | 1 | 30 | 0.55 | 500 | - | SMA-L |
| SK14.pdf | 1 | 40 | 0.6 | 500 | - | SMA-L |
| SK22.pdf | 2 | 20 | 0.5 | 500 | - | SMA-L |
| SK23.pdf | 2 | 30 | 0.5 | 500 | - | SMA-L |
| SK24.pdf | 2 | 40 | 0.5 | 500 | - | SMA-L |
| SK25.pdf | 2 | 50 | 0.7 | 500 | - | SMA-L |
| SK26.pdf | 2 | 60 | 0.7 | 500 | - | SMA-L |
| SK210.pdf | 2 | 100 | 0.85 | 500 | - | SMA-L |
| SK32.pdf | 3 | 20 | 0.5 | 500 | - | HSMB |
| SK33.pdf | 3 | 30 | 0.5 | 500 | - | HSMB |
| SK34.pdf | 3 | 40 | 0.5 | 500 | - | HSMB |
| SK35.pdf | 3 | 50 | 0.7 | 500 | - | HSMB |
| SK36.pdf | 3 | 60 | 0.7 | 500 | - | HSMB |
| SK310.pdf | 3 | 100 | 0.85 | 500 | - | HSMB |
| RS1A.pdf | 1 | 50 | 1.3 | 5 | 150 | SMA |
| RS1B.pdf | 1 | 100 | 1.3 | 5 | 150 | SMA |
| RS1D.pdf | 1 | 200 | 1.3 | 5 | 150 | SMA |
| RS1G.pdf | 1 | 400 | 1.3 | 5 | 150 | SMA |
| RS1J.pdf | 1 | 600 | 1.3 | 5 | 250 | SMA |
| RS1K.pdf | 1 | 800 | 1.3 | 5 | 500 | SMA |
| RS1M.pdf | 1 | 1000 | 1.3 | 5 | 500 | SMA |
| FS1A.pdf | 1 | 50 | 1.3 | 5 | 150 | SMA |
| FS1B.pdf | 1 | 100 | 1.3 | 5 | 150 | SMA |
| FS1D.pdf | 1 | 200 | 1.3 | 5 | 150 | SMA |
| FS1G.pdf | 1 | 400 | 1.3 | 5 | 150 | SMA |
| FS1J.pdf | 1 | 600 | 1.3 | 5 | 250 | SMA |
| FS1K.pdf | 1 | 800 | 1.3 | 5 | 500 | SMA |
| FS1M.pdf | 1 | 1000 | 1.3 | 5 | 500 | SMA |
| RS2A.pdf | 2 | 50 | 1.3 | 5 | 150 | SMB |
| RS2B.pdf | 2 | 100 | 1.3 | 5 | 150 | SMB |
| RS2D.pdf | 2 | 200 | 1.3 | 5 | 150 | SMB |
| RS2G.pdf | 2 | 400 | 1.3 | 5 | 150 | SMB |
| RS2J.pdf | 2 | 600 | 1.3 | 5 | 250 | SMB |
| RS2K.pdf | 2 | 800 | 1.3 | 5 | 500 | SMB |
| RS2M.pdf | 2 | 1000 | 1.3 | 5 | 500 | SMB |
| F21.pdf | 2 | 50 | 1.3 | 5 | 150 | SMA-L |
| F22.pdf | 2 | 100 | 1.3 | 5 | 150 | SMA-L |
| F23.pdf | 2 | 200 | 1.3 | 5 | 150 | SMA-L |
| F24.pdf | 2 | 400 | 1.3 | 5 | 150 | SMA-L |
| F25.pdf | 2 | 600 | 1.3 | 5 | 250 | SMA-L |
| F26.pdf | 2 | 800 | 1.3 | 5 | 500 | SMA-L |
| F27.pdf | 2 | 1000 | 1.3 | 5 | 500 | SMA-L |
| F31.pdf | 3 | 50 | 1.3 | 5 | 150 | SMC |
| F32.pdf | 3 | 100 | 1.3 | 5 | 150 | SMC |
| F34.pdf | 3 | 400 | 1.3 | 5 | 150 | SMC |
| F35.pdf | 3 | 600 | 1.3 | 5 | 250 | SMC |
| F36.pdf | 3 | 800 | 1.3 | 5 | 500 | SMC |
| F37.pdf | 3 | 1000 | 1.3 | 5 | 500 | SMC |
| ES1A.pdf | 1 | 50 | 0.95 | 5 | 35 | SMA |
| ES1B.pdf | 1 | 100 | 0.95 | 5 | 35 | SMA |
| ES1D.pdf | 1 | 200 | 0.95 | 5 | 35 | SMA |
| ES1G.pdf | 1 | 400 | 0.95 | 5 | 35 | SMA |
| ES1J.pdf | 1 | 600 | 1.3 | 5 | 35 | SMA |
| ES1K.pdf | 1 | 800 | 1.7 | 5 | 35 | SMA |
| ES1M.pdf | 1 | 1000 | 1.7 | 5 | 35 | SMA |
| ES2A.pdf | 2 | 50 | 0.975 | 5 | 50 | SMA |
| ES2B.pdf | 2 | 100 | 0.975 | 5 | 50 | SMA |
| ES2D.pdf | 2 | 200 | 0.975 | 5 | 50 | SMA |
| ES2G.pdf | 2 | 400 | 1.35 | 5 | 60 | SMA |
| ES2J.pdf | 2 | 600 | 1.35 | 5 | 60 | SMA |
| ES2K.pdf | 2 | 800 | 1.75 | 5 | 100 | SMA |
| ES2M.pdf | 2 | 1000 | 1.75 | 5 | 100 | SMA |
| US1A.pdf | 1 | 50 | 1 | 5 | 50 | HSMA |
| US1B.pdf | 1 | 100 | 1 | 5 | 50 | HSMA |
| US1D.pdf | 1 | 200 | 1.3 | 5 | 50 | HSMA |
| US1G.pdf | 1 | 400 | 1.3 | 5 | 50 | HSMA |
| US1J.pdf | 1 | 600 | 1.7 | 5 | 75 | HSMA |
| US1K.pdf | 1 | 800 | 1.7 | 5 | 75 | HSMA |
| US1M.pdf | 1 | 1000 | 1.7 | 5 | 75 | HSMA |
| US2A.pdf | 2 | 50 | 1 | 5 | 50 | HSMB |
| US2B.pdf | 2 | 100 | 1 | 5 | 50 | HSMB |
| US2D.pdf | 2 | 200 | 1 | 5 | 50 | HSMB |
| US2G.pdf | 2 | 400 | 1.3 | 5 | 50 | HSMB |
| US2J.pdf | 2 | 600 | 1.7 | 5 | 75 | HSMB |
| US2K.pdf | 2 | 800 | 1.7 | 5 | 75 | HSMB |
| US2M.pdf | 2 | 1000 | 1.7 | 5 | 75 | HSMB |
| H11.pdf | 1 | 50 | 1 | 5 | 50 | SMA-L |
| H12.pdf | 1 | 100 | 1 | 5 | 50 | SMA-L |
| H13.pdf | 1 | 200 | 1 | 5 | 50 | SMA-L |
| H14.pdf | 1 | 400 | 1.3 | 5 | 50 | SMA-L |
| H15.pdf | 1 | 600 | 1.3 | 5 | 50 | SMA-L |
| H16.pdf | 1 | 800 | 1.7 | 5 | 75 | SMA-L |
| H17.pdf | 1 | 1000 | 1.7 | 5 | 75 | SMA-L |
| H21.pdf | 2 | 50 | 1 | 5 | 50 | SMA-L |
| H22.pdf | 2 | 100 | 1 | 5 | 50 | SMA-L |
| H23.pdf | 2 | 200 | 1 | 5 | 50 | SMA-L |
| H24.pdf | 2 | 400 | 1.3 | 5 | 50 | SMA-L |
| H25.pdf | 2 | 600 | 1.3 | 5 | 50 | SMA-L |
| H26.pdf | 2 | 800 | 1.7 | 5 | 75 | SMA-L |
| H27.pdf | 2 | 1000 | 1.7 | 5 | 75 | SMA-L |
| H31.pdf | 3 | 50 | 1 | 5 | 50 | SMC |
| H32.pdf | 3 | 100 | 1 | 5 | 50 | SMC |
| H33.pdf | 3 | 200 | 1 | 5 | 50 | SMC |
| H34.pdf | 3 | 400 | 1.3 | 5 | 50 | SMC |
| H35.pdf | 3 | 600 | 1.3 | 5 | 50 | SMC |
| H36.pdf | 3 | 800 | 1.7 | 5 | 75 | SMC |
| H37.pdf | 3 | 1000 | 1.7 | 5 | 75 | SMC |
| S11.pdf | 1 | 50 | 0.95 | 5 | 35 | SMA-L |
| S12.pdf | 1 | 100 | 0.95 | 5 | 35 | SMA-L |
| S13.pdf | 1 | 150 | 0.95 | 5 | 35 | SMA-L |
| S14.pdf | 1 | 200 | 0.95 | 5 | 35 | SMA-L |
| S15.pdf | 1 | 300 | 1.25 | 5 | 35 | SMA-L |
| S16.pdf | 1 | 400 | 1.25 | 5 | 35 | SMA-L |
| S17.pdf | 1 | 500 | 1.7 | 5 | 35 | SMA-L |
| S18.pdf | 1 | 600 | 1.7 | 5 | 35 | SMA-L |
| S31.pdf | 3 | 50 | 0.95 | 5 | 35 | SMC |
| S32.pdf | 3 | 100 | 0.95 | 5 | 35 | SMC |
| S33.pdf | 3 | 150 | 0.95 | 5 | 35 | SMC |
| S34.pdf | 3 | 200 | 0.95 | 5 | 35 | SMC |
| S35.pdf | 3 | 300 | 1.25 | 5 | 35 | SMC |
| S36.pdf | 3 | 400 | 1.25 | 5 | 35 | SMC |
| S37.pdf | 3 | 500 | 1.7 | 5 | 35 | SMC |
| S38.pdf | 3 | 600 | 1.7 | 5 | 35 | SMC |
